                     Timing belt Product List

Model

Pitch  P

Tooth angle B°

Tooth root thickness  S

Tooth height H1

Band thickness H

Timing belt 10mm

50mm 同步带最大

100mm 同步带

Min. allowable no. of teeth

Heavy load(N)

负载 (N)

最大负载(N)

Open

Connection

Open

Connection

Open

Connection

MXL

2.032

40

1.14

0.51

1.14



10

XXL

3.175

50

1.73

0.76

1.52



10

XL

5.08

50

2.57

1.27

2.3

260

130

740

370

3170

1585

12

L

9.525

40

4.65

1.91

3.6

558

279

1570

785

3410

1705

14

H

12.7

40

6.12

2.29

4.3

936

468

2340

1170

5120

2560

14

XH

22.225

40

12.57

6.35

11.2

588

294

3560

1780

7180

3590

17

XXH

31.75

40

19.05

9.53

15.7



30

T2.5

2.5

40

1.5

0.7

1.3

240

120

1440

720

2800

1400

10

T5

5

40

2.65

1.2

2.2

350

175

1764

882

3340

1670

12

T10

10

40

5.3

2.5

4.5

870

435

4980

2490

10560

5280

14

T20

20

40

10.15

5

8

1285

642

7250

3625

15680

7840

17

AT3

3

50

2.4

1.1

1.9



12

AT5

5

50

3.75

1.2

2.7

520

260

3410

1705

6900

3450

14

AT10

10

50

7.3

2.5

4.5

1210

605

7760

3380

14750

7375

14

AT15

15

50

10.85

3.7

6.5

1579

789

9800

4900

18854

9427

16

AT20

20

50

14.7

5

8

1880

940

11456

5728

22958

11479

25

3M

3

14

1.78

1.22

2.4

300

150

1560

780

3650

1825

12

5M

5

14

3.05

2.06

3.8

860

430

4960

2480

10200

5100

14

8M

8

14

5.15

3.38

6

1350

675

7210

3605

14650

7325

17

14M

14

14

9.4

6.02

10

1900

960

11572

5786

23190

11595

25

20M

20

14

14

8.4

13.2



30

S2M

2



1.3

0.84

1.36



10

S3M

3



1.95

1.14

2.4

300

150

1560

780

3650

1825

12

S5M

5



3.15

1.9

3.4

860

430

4960

2480

10200

5100

14

S8M

8



5.2

3

5.6

1350

675

7210

3605

14650

7325

17

S14M

14



9.1

5.3

10

1900

950

11572

5786

23190

11595

25

RPP5M

5



3

1.95

3.4

860

430

4960

2480

10200

5100

14

RPP8M

8



5.5

3.3

5.6

1350

675

7210

3605

14650

7325

17

RPP14M

14



9.18

5.85

10

1900

950

11572

5786

23190

11595

25
